Allen&Heath ZED 18 mixér

Allen & Heath ZED 18

ZED-18 has an incredibly advanced feature-set for a mixer at this level – it gives musicians, venues and hire companies access to 10 full mono channels and 4 stereo channels in a compact, rack mountable format. Configurable USB audio in/out makes it easy to capture stereo recordings.

• microphone or line inputs: 10
• Stereo inputs: 4 (double)
• Low-cut filter: 100Hz
• Correction of color and mono channels 3-stage with 2 plies EQ frequencies: 80Hz and 12kHz and a parametric equalizer operating in the range of 120Hz-4kHz
• Stereo channels: 2-stage with 2 plies EQ frequencies: 80Hz and 12kHz. Correction range +/- 15dB
• Shipping (AUX) AUX1, AUX2 (pre); AUX3, AUX4 (post)
• Phantom Power: + 48V (global)
• Slots Insertion: on each mono channel and total
• USB Port: USB 1.1 allows to send two signals to and from the computer 2 with a resolution of 16 bit and bitowej- sampling frequencies: 32, 44.1 and 48kHz. Includes program Sonar X1 LE
• Gates: 100mm with dust cover
• Outputs: Main Out L / R, Mono Out, Alt Out Rec Out
• Dimensions: 465x98x464mm
• Weight: 8.5kg
