TW AUDiO C15 jevištní monitor

TW Audio C15

Built to the same exacting standard, the C15 and C12 share a strong visual aesthetic and have been designed to seamlessly and discreetly blend into any environment. Straight out of the box, your C-series monitor will operate on a single amplifier channel without the need for additional controllers or EQ.

Identical in cross section, the monitor boasts a low-profile wedge-shaped enclosure containing coaxial chassis with a 15" low frequency woofer and a 1.4" mid-high frequency tweeter with a 3" voice coil. The large mid-high horn ensures perfect mid-high frequency dispersion while its passive frequency crossover produces accurate and phase-coherent summation of low and mid-high frequencies. The low crossover frequency of the mid-high driver is particularly suited to very high quality speech reproduction.

Especially when additional bass extension is required, the C15 will offer a robust low end response, refined with the enclosure's generously dimensioned bass reflex channels for a tightly defined, punchy response that you will feel as well as hear.

The C15 also benefits from the added versatility which comes from being able to run in two-way active mode. For flexibility, the C15 can be mounted on a pole, or on surfaces using the specially developed svivel bracket SBC15 which attaches using a latching mechanism, meaning assembly does not require tools or separate, easily lost parts.

No matter whether they are used as monitors or as full range speakers, TW AUDiO's C-series enclosures combine high performance, versatility and full integration with the entire TW AUDiO range.

Specifications:

• Drivers: LF: 1 × 15", HF: 1 × 1.4" coaxial exit with 3" diaphragm
• Frequency range: 55 – 17000 Hz
• Power capacity program / peak: 800 W (bi-amp LF), 320 W (bi-amp HF),n800 / 1600 W (passive)
• Impedance: 8 Ohms (bi-amp LF), 20 Ohms (bi-amp HF)
8 Ohms (passive)
• Coverage (h x v): in monitor use 55° × 70° HF-horn, rotatable
• Sensitivity 1 W / 1 m: 101 dB
• SPLmax / 1 m: 133 dB
• Connection: NL4 1± HF / 2± LF (bi-amp)
• NL4 1± (passive)
• Dimensions (H x W x D) : 348 × 605 × 500 mm [13.7 × 23.82 × 19.69 in]
• Weight: 23,8 kg [52 lbs]
• Finish: Warnex texture paint
